Labnics ESR Analyzer NERA-100 measures the erythrocyte sedimentation rate of blood samples using an infrared sensor that reads each tube automatically. It loads 20 samples at the same time in random positions, with a 3-minute interval between samples. Tests run for 30 or 60 minutes, which gives a throughput of up to 40 samples per hour. Results appear as Westergren ESR values from 1 to 140 mm/h, with temperature compensation to 18 °C available as a selectable setting. This automated ESR analyzer handles routine sedimentation testing in batches.
$3,225.00
| Field of application | Erythrocyte sedimentation rate (ESR) analysis |
| Measuring principle | Infrared sensor |
| Analysis result | Westergren ESR value (mm/hr) |
| Throughput | Up to 40 samples per hour |
| Reading channels | 20 |
| Loading capacity | 20 samples at the same time |
| Loading pattern | Random |
| Measuring time | 30 minutes or 60 minutes selectable |
| Sample interval | 3 minutes |
| Measurement range | 1 to 140 mm/h |
| Temperature compensation | Refer to 18 °C automatically (selectable) |
| Reading resolution | ±0.1 mm |
| Result resolution | 1 mm/1 h, 1 mm/2 h |
| Blood level range | 50 to 64 mm |
| Display | Colour LCD screen |
| Input | Touch screen |
| Interface | RS-232 serial port |
| Internal thermal recorder | |
| Storage | 4,000 results |
| Power supply | AC 100–240 V, 50/60 Hz, 50 W |
| Operating temperature | 5 °C to 40 °C |
| Operating humidity | ≤80% |
| Dimensions (W × D × H) | 365 × 300 × 180 mm |
| Net weight | 11 kg |
Infrared Detection — Infrared sensor reads each sample for ESR measurement
Random Loading — Samples can be placed in any of the 20 channels
Selectable Test Time — 30 or 60 minute tests with a 3-minute sample interval
Temperature Compensation — Refers readings to 18 °C automatically, selectable
Result Printing — Internal thermal recorder prints results
Haematology Laboratories | Pathology Laboratories | Research Laboratories |
Erythrocyte sedimentation rate analysis, Westergren ESR measurement | Batch ESR testing, 30 or 60 minute tests | ESR sample testing, printed and stored results |
Labnics ESR Analyzer processes multiple samples quickly and efficiently for fast and reliable results. They offer large data storage capacity for extensive data management. These analyzers include a built-in printer for direct and effortless result printing. Our units feature user-friendly touchscreen interfaces for easy operation. They provide graphical representations of erythrocyte sedimentation for detailed analysis.
